Supported Packaging Formats
Specifications
| Standard (4 Division Type) | 3 / 6 Division Type | Large Capacity | |
| Type | Option to fit Twin Lane 4 Side Seal Type | ||
| Line Speed | 4 – 30 m/min | ||
| Sealing Pitch | 40 – 160mm | 70 – 180mm (3 Division) | 40 – 160mm (Standard) 100 – 250mm (Large 1) 100 – 250mm (Large 2) |
| 30 – 90mm (6 Division) | |||
| Filling Volume | 3g – 100g | 1.5g – 100g | 5g – 100g (Standard) 5g – 350g (Large 1) 5g – 500g (Large 2) |
| Filling volume varies with Twin Lane 4 Side Seal Option | |||
| Maximum Output | 400 pcs / min | 500 pcs / min (6 Division) | 400 pcs / min (Standard) 150 pcs / min (Large 1) 60 pcs / min (Large 2) |
| The output will be doubled with the Twin Lane 4 Side Seal Option | |||
| Dimensions | W 1450mm ✕ D 980mm ✕ H 2200mm | ||
| Mass | ~1,350kg | ||
| Utilities Required | Electricity: AC 200V ±20V 4.8kVA Air Pressure: 5 bar |
||
Lorem ipsum dolor sit amet consectetur.
Lorem ipsum dolor sit amet consectetur Lorem ipsum dolor sit amet consectetur .
- Lorem ipsum dolor sit amet consectetur
- Lorem ipsum dolor sit amet consectetur
- Lorem ipsum dolor sit amet consectetur
- Lorem ipsum dolor sit amet consectetur
- Lorem ipsum dolor sit amet consectetur
Lorem ipsum dolor sit amet.
Lorem ipsum dolor sit amet consectetur Lorem ipsum dolor sit amet consectetur . Lorem ipsum dolor sit amet consectetur
- Lorem ipsum dolor sit amet consectetur
- Lorem ipsum dolor sit amet consectetur /li>
- Lorem ipsum dolor sit amet consectetur
- Lorem ipsum dolor sit amet consectetur
Lorem ipsum dolor sit amet.
Lorem ipsum dolor sit amet consectetur Lorem ipsum dolor sit amet consectetur . Lorem ipsum dolor sit amet consectetur
"Lorem ipsum dolor sit amet consectetur Lorem ipsum dolor sit amet consectetur Lorem ipsum dolor sit amet consectetur"
- Lorem ipsum dolor sit amet consectetur
Wide range of Cutter Blade
Taisei Lamick’s option of Flat Cut, Perforated Cut, and Wave Cutter, gives the user, freedom to choose their sachet outlook.
Customisable Seal Bar
Seal bars are interchangeable, giving you a freedom to stylise your pouch.
Airless Seal Options
Selection of squeezers to attain airless seal that helps in extending shelf life of the product.
Left : With Liquid Squeeze Roller
Right : Without Liquid Squeeze Roller
Standard Pre Heater
The Standard Pre Heater module helps to condition the material before sealing during high speed operation.
Strengthening Pre Heater
For packaging that require higher sealing temperature or ultra high speed operations, Strengthening Pre-heaters are a useful add-on options. Options available : Left (pictured), Middle & Right Unit to suit user’s need.
